BLASTRAC
Blastrac shot blasting machine 1-8DPS30 (Single phase)
A walk-behind shotblasting machine
The Blastrac 1-8DPS30 shot blast-cleaning machine is perfect for small to medium-sized jobs. 1-8DPS30 is a heavy duty and reliable enough to be suitable for rental use. 1-8DPS30 is a walk-behind machine that when connected to an appropriate Blastrac dust collector provides a virtually dust-free, and friendly environment.
| |
| |
| |
| |
| |
| |
| |
|
Applications
The 1-8DPS30 walk behind blast-cleaning machine is an ideal tool for any surface preparation application. Lightweight and portable, it can handle most small and medium-sized jobs on its own, this machine is perfectly suited for concrete restoration, industrial flooring preparation, renovation, maintenance and much more, to receive advice or training about shot blasting or to find the best products for your surface preparation applications, contact Blastrac.
Video about the 1-8DPS30
Technical Specifications 1-8DPS30
| Name | Description |
| Working width | 203mm |
| Blasting capacity | Up to 50m²/h on concrete |
| Motor | 3,0kW / 230V - 50Hz or 60Hz / 16A - Single phase 3,0kW / 400V - 50Hz or 60Hz / 16A - three phase – 5 pole |
| Weight | 125 kg |
| Dimensions (L,W,H) | 1310mm / 400mm / 1200mm |
| Drive system / speed | Electric / 0 – 23 m/min |
| Working direction | Forward (push) |
| Abrasive consumption | 10 – 75 gr/m² |
| Surface | Steel / Concrete / Stone / Asphalt |
Options / Accessories 1-8DPS30
| Name | Description |
| Dustcollector | BDC-1330 / BDC-317 |
| Abrasive S330 / S390 | 999-0330 / 999-0390 |
| 10m suction hose Ø75 | 005014 |
| Magnetic sweeper | 489538 |
| Magnetic broom R600 | 001238 |
| Maintenance kit | 000142 |
| Personal safety features | On request / See manual |
BLASTRAC CATALOGUES
Open publication - Free publishing
Open publication - Free publishing
Open publication - Free publishing
Open publication - Free publishing
Open publication - Free publishing
Open publication - Free publishing
Open publication - Free publishing
SPECIFICATIONS
Part Number: 1-8DECProduction Capacity: 350 sq. ft./hr.
Cleaning Path: 8”
Travel Speed: Manual
Blast Motor: 3 h.p.
Voltage: 230 V, 1ø, 60 Hz
Amperage: 16.8 A
Minimum Generator: 15 kW
Dimensions: L 47” x W`12” x H 39”
Weight: 181 lb.
Dust Collector: BDC-1216 or BDC-1324
The Blastrac 1-8DEC is an easy-to-use, versatile shot blast system designed for the entry level contractor, or for use as a complementary unit or edging unit for the medium or large contractor. An optional caster kit makes the system highly maneuverable and helps provide for a more consistent, even profile.
The Blastrac 1-8DEC is useful for residential garage floors, balconies, pool decks, tight areas around equipment and obstructions, and test patches. It is also used for concrete preparation prior to installation of wood flooring and is great for PVC decorative stenciling.
The Blastrac 1-8DEC is useful for residential garage floors, balconies, pool decks, tight areas around equipment and obstructions, and test patches. It is also used for concrete preparation prior to installation of wood flooring and is great for PVC decorative stenciling.
FEATURES & BENEFITS:
- 8” blast pattern
- Manual travel speed
- Prepares 50 to 350 sq. ft./hr.
- Runs on 230 volt, single phase power
- Use for light to heavy removal
- In corners, can clean to within 1½” of the front wall
- Front casters make the system highly maneuverable and help provide for a more consistent, even profile; removable for edging
- Operates in forward (push) direction
- Lightweight unit is easy to handle and transport
2-45DTM
SPECIFICATIONS
Blast Wheel Power: 2, 40 hp (30kW) hydraulic motorsWork Speed: Maximum up to 3 mph (4.7 km/hr)
Working Width: 45 in. (1,150 mm)
Blast Head Weight: 3,858 lbs (1,750 kg)
Dimensions: L 59 in. x W 51in. x H 51in. (1,500 mm x 1,300 mm x 1,300 mm)
Blasting Capacity: Up to 38,750 sq.ft/hr (3,600 m2/hr) on concrete
Package Options:
A. 2-45D Package: Includes blast head; dust collector and blower; adaptor kit for rear or front
mount: To be assembled by a certified hydraulic specialist on a customer’s vehicle that will meet or exceed Blastrac’s criteria.
B. 2-45DTM Turnkey Package: as above (2-45D) and also includes truck with full assembly by Blastrac factory specialists. Starter Kit: Initial charge of steel abrasive, magnetic broom 32 in. (800 mm) and blast head maintenance kit.
Blastrac’s 2-45DTM truck-mounted shot blaster is one of the most adaptable and productive of the large horizontal blast cleaning machines in our equipment line. The DOT highway approved vehicle is completely self-contained and specifically designed for surface preparation specialists doing jobs that require limited downtime, such as airports, highways, bridges and other large projects. The 2-45DTM provides a virtually dust-free, environmentally friendly work environment for the operator and others on the same site. The remarkable 2-45DTM converts from a transport to a high production, environmentally friendly, shot blasting road machine.
Specialty contractors can drive to the job with all equipment, personnel, and supplies safely in a single vehicle. All controls, dust collection, spares, consumables, and the blast head, are protected in an enclosed truck body equipped with a lift-gate. Work is started after quick mounting of the blast head, converting the over-the-road vehicle to effective work machine.
The 2-45DTM shot blaster is perfectly suited for road maintenance, asphalt retexturing, bridge deck preparation, airport maintenance and much more. It is also designed for skid resistance enhancement on roads, bridges, and runways. Road/runway markings removal or compounded-rubber removal can also be completed with virtually no dust, debris or water.
Specialty contractors can drive to the job with all equipment, personnel, and supplies safely in a single vehicle. All controls, dust collection, spares, consumables, and the blast head, are protected in an enclosed truck body equipped with a lift-gate. Work is started after quick mounting of the blast head, converting the over-the-road vehicle to effective work machine.
The 2-45DTM shot blaster is perfectly suited for road maintenance, asphalt retexturing, bridge deck preparation, airport maintenance and much more. It is also designed for skid resistance enhancement on roads, bridges, and runways. Road/runway markings removal or compounded-rubber removal can also be completed with virtually no dust, debris or water.
FEATURES & BENEFITS:
- Prepares up to 38,750 sq.ft/hr (3,600 m2/hr) on concrete or asphalt (relevant to hardness and asphalt mix)
- Magnetic/air-wash dust collection system for separating contaminants from abrasives with containment and disposal of debris
- 2, 40HP (30kW) hydraulic blast motors
- Versatile, heavy duty and highly productive machine
- Flexible use for any job site, no trailers or special transport required
- Designed for optimum use on asphalt and concrete surfaces
- Uniform 45 inch blast pattern for consistent results
1-8DEC
SPECIFICATIONS
Part Number: 1-8DECProduction Capacity: 350 sq. ft./hr.
Cleaning Path: 8”
Travel Speed: Manual
Blast Motor: 3 h.p.
Voltage: 230 V, 1ø, 60 Hz
Amperage: 16.8 A
Minimum Generator: 15 kW
Dimensions: L 47” x W`12” x H 39”
Weight: 181 lb.
Dust Collector: BDC-1216 or BDC-1324
The Blastrac 1-8DEC is an easy-to-use, versatile shot blast system designed for the entry level contractor, or for use as a complementary unit or edging unit for the medium or large contractor. An optional caster kit makes the system highly maneuverable and helps provide for a more consistent, even profile.
The Blastrac 1-8DEC is useful for residential garage floors, balconies, pool decks, tight areas around equipment and obstructions, and test patches. It is also used for concrete preparation prior to installation of wood flooring and is great for PVC decorative stenciling.
The Blastrac 1-8DEC is useful for residential garage floors, balconies, pool decks, tight areas around equipment and obstructions, and test patches. It is also used for concrete preparation prior to installation of wood flooring and is great for PVC decorative stenciling.
FEATURES & BENEFITS:
- 8” blast pattern
- Manual travel speed
- Prepares 50 to 350 sq. ft./hr.
- Runs on 230 volt, single phase power
- Use for light to heavy removal
- In corners, can clean to within 1½” of the front wall
- Front casters make the system highly maneuverable and help provide for a more consistent, even profile; removable for edging
- Operates in forward (push) direction
- Lightweight unit is easy to handle and transport
Accessories
Blastrac offers a full range of accessories for a large variety of our products. Blastrac accessories are the ideal complement to Blastrac tools to ensure a quality result for your surface application needs. Blastrac offers accessories and wear parts perfectly suited for your job requirements.
Blastrac provides a full line of accessories for our:
- Multitask vehicles
- Shot blasting machines
- Steel blasting machines
- Single and planetary grinding machines
- Scarifying machines
- Stripping machines
- Sawing machines
- Handheld equipment
- Dust collecting systems
Most of our accessories and wear parts are suitable for other similar brands as well.
Always use Blastrac genuine spares and tools: they were specially designed for heavy duty professional use and will ensure a longer life time of your equipment. If you would further information on the Blastrac line of accessories, wearable parts or replacement parts, please contact us today!
